Heavy hammer crusher

Applicable materials: Various limestone, bluestone, marble, granite, sandstone, pebbles and other medium-hard stones with compressive strength ≤200MPa can be "hammered to pieces" with a large crushing ratio

Processing capacity: 60-3200t/h

Feed size: ≤1200mm

Get Quotes

Product Introduction

PCZ hammer crusher is suitable for crushing various medium hardness and brittle materials. PCZ hammer crusher has large crushing ratio, high production efficiency, complete models, and PCZ hammer crusher is equipped with reliable crushing technology. Compared with previous models, it can crush stones into well-shaped particles under primary crushing. In recent years, it has become the best choice for rock crushing in mining, smelting, chemical and other industries.

Finished product specifications: 5, 12, 13 stones

Application range: mining, smelting, chemical industry, highway and other industrial sectors

Product advantages

Reduce costs and increase profits: the stone is formed in one step, no secondary crushing is required, the crushing process is simplified, the user's investment is reduced, and the equipment has high production efficiency, which increases the user's profits.

Wide application and good crushing: It can be used to crush various stones with a compressive strength of ≤200MPa. It is widely used and has a large crushing ratio. It can be used in large stone production lines.

Automated and safer: The automated structural design can automatically monitor the oil temperature of the oil pump and oil tank to ensure that the daily operation and operation of the equipment are safer and more reliable.

More energy-saving and less pollution: The modular structural design can meet the free conversion of coarse, medium and fine crushing of stones, save energy and reduce consumption, and the equipment operation is less polluting and more environmentally friendly.

Products Parameters

model	Rotor diameter x length (mm)	Feed opening length x width (mm)	Feed size(mm)	Processing capacity(t/h)	power(kw)	Specification L×W×H (mm)
PCZ1308	Φ1330×790	870×780	≤380	60-160	132	2880×2130×2390
PCZ1410	Φ1400×1000	1060×740	≤450	80-210	2×90(180)	2830×2100×2485
PCZ1610	Φ1600×1000	1090×930	≤480	100-230	2×132	3370×2415×2750
PCZ1612	Φ1600×1200	1340×1140	≤500	120-350	2×160	3370×2613×2750
PCZ1615	Φ1600×1500	1570×1140	≤550	200-550	2×200	3370×2925×2750
PCZ1716	Φ1700×1600	1420×1200	≤600	400-850	2×250	3520×3000×3210
PCZ1720	Φ1700×2000	2030×1200	≤650	500-1000	2×400	3670×3390×3330
PCZ1920	Φ1900×2000	1980×1210	≤750	800-1500	2×500	4490×3910×3600
PCZ2225	Φ2200×2500	2530×1610	≤1000	1500-3000	1250	4890×5010×4560
