Mixing bucket
Product use: Mixing of ore pulp with a concentration not exceeding 30% and an ore density not exceeding 3.5 and flotation reagents.
Effective volume: 0.26-30m3
Power range: 1.1-22kw
Product use: Mixing of ore pulp with a concentration not exceeding 30% and an ore density not exceeding 3.5 and flotation reagents.
The mixing barrel is mainly used in various metal mining industries for mixing materials and medicines before flotation. It can also be used for mixing non-metallic minerals.
It is suitable for materials with a concentration of less than 30% and a particle size of less than 1 mm. In addition, it looks like a flat barrel with a spiral flow channel in which materials can be moved and mixed.
Mixing of ore pulp with a concentration not exceeding 30% and an ore density not exceeding 3.5 and flotation reagents.
1. Compact structure and reliable sealing.
2. It has the advantages of uniform mixing, propeller fan shape, and high contact specific gravity.
3. There are many rows of nozzles to ensure uniform water flow.
4. There is a watershed at the bottom. So the whole machine is very clean.
5. Advanced equipment performance. Stable production quality. Uniform mixing.
| Model | Effective Volume (m³) | Impeller Speed (r.p.m) | Diameter of Impeller (mm) | Motor Type | Motor Power (kw) | Weight (kg) |
|---|---|---|---|---|---|---|
| BJ-500×500 | 0.074 | 525 | 240 | Y802-4 | 0.75 | 162 |
| BJ-750×750 | 0.25 | 530 | 240 | Y10OL-6 | 1.5 | 305 |
| BJ-1000×1000 | 0.58 | 513 | 230 | Y90L-4 | 1.5 | 680 |
| BJ-1250×1250 | 1.4 | 401 | 380 | Y100L1-4 | 2.2 | 1008 |
| BJ-1500×1500 | 2.1 | 332 | 380 | Y132M1-6 | 4 | 1310 |
| BJ-1600×1600 | 2.56 | 332 | 380 | Y132M2-6 | 5.5 | 1630 |
| BJ-2000×2000 | 5.46 | 305 | 550 | Y160M-6 | 7.5 | 1900 |
| BJ-2000×2500 | 5.97 | 285 | 630 | Y160M-6 | 7.5 | 2360 |
| BJ-2500×2500 | 10 | 285 | 630 | Y160L-6 | 11 | 2766 |
| BJ-3000×3000 | 19.1 | 200 | 800 | Y225M-8 | 22 | 4808 |
| BJ-3500×3500 | 29.5 | 190 | 800 | Y225M-8 | 22 | 5580 |
| BJ-3550×4000 | 35 | 194 | 850 | Y250M-8 | 30 | 5939 |
| BJ-4000×4000 | 46 | 210 | 1000 | Y280S-8 | 37 | 8036 |
| Model | Effective Volume (m³) | Impeller Speed (r.p.m) | Diameter of Impeller (mm) | Motor Type | Motor Power (kw) | Weight (kg) |
|---|---|---|---|---|---|---|
| BJN-1000×1000 | 0.58 | 530 | 400 | Y132M2-6 | 5.5 | 1700 |
| BJN-1500×1500 | 2.25 | 280 | 500 | Y180L-6 | 15 | 2210 |
| BJN-2000×2000 | 5.8 | 250 | 650 | Y200L2-6 | 22 | 2985 |
| BJN-3000×3000 | 19.1 | 210 | 700 | Y225M-8 | 30 | 4660 |
| BJN-3500×3500 | 30 | 194 | 850 | Y250M-8 | 37 | 5639 |
| BJN-4000×4000 | 46 | 121.6 | 1000 | Y280S-8-B3 | 45 | 8156 |
| Model | Effective Volume (m³) | Impeller Speed (r.p.m) | Diameter of Impeller (mm) | Motor Type | Motor Power (kw) | Weight (kg) |
|---|---|---|---|---|---|---|
| BJW-500×500 | 0.074 | 525 | 240 | Y802-4 | 0.75 | 142 |
| BJW-500×600 | 0.094 | 525 | 240 | Y802-4 | 0.75 | 210 |
| BJW-750×750 | 0.25 | 530 | 240 | Y100L-6 | 1.5 | 280 |
| BJW-1000×1000 | 0.58 | 513 | 230 | Y90L-4 | 1.5 | 420 |
| BJW-1250×1250 | 1.4 | 401 | 380 | Y100L1-4 | 2.2 | 973 |
| BJW-1500×1500 | 2.2 | 320 | 380 | Y132M1-6 | 4 | 1265 |
| BJW-1600×1600 | 2.56 | 332 | 380 | Y132M2-6 | 5.5 | 1530 |
| BJW-2000×2000 | 5.46 | 233 | 550 | Y132M2-6 | 5.5 | 1850 |
| BJW-2500×2500 | 11.2 | 285 | 630 | Y160L-6 | 11 | 2681 |
| BJW-3000×3000 | 17.5 | 200 | 800 | Y225M-8 | 22 | 4620 |
| BJW-3500×3500 | 29.5 | 190 | 800 | Y225M-8 | 22 | 5380 |
| BJW-4000×4000 | 46 | 200 | 1000 | Y250M-8 | 30 | 7850 |
