High efficiency concentrator

Product use: Dehydration of various ore concentrates and tailings

Product inner diameter: 1.8-100m

Processing capacity: 5.6-6250t/d

Get Quotes

60s Manual Response

24-hour Free Solution

1-10 Days Shipping

Quick Installation

One Year Warranty

Factory Direct Sales

Product Introduction

The high-efficiency concentrator is mainly used for dewatering tailings in flotation concentrate beneficiation plants, and is also used for the concentration and purification of liquids containing solid particles in the metallurgical, chemical, coal, building materials and sewage treatment industries.

In fact, it is not just a sedimentation device, but a new type of dewatering equipment combined with the filtration characteristics of the mud layer.

Product use

Dehydration of various ore concentrates and tailings

Product advantages

1. Adding flocculants increases the particle size of settled solid particles, thereby accelerating the settling speed.

2. Installing inclined plates shortens the settling distance of mineral particles and increases the settling area.

3. Plays the role of flocculation, filtration, compression and increasing the processing capacity of the dense phase layer of mud deposition.

4. Equipped with complete automatic control facilities.

Frequently asked questions

Why is sludge the most difficult to deal with? How to deal with it?

For colloidal particles with a particle size of 0.1-0.001 microns, there is actually no precipitation due to molecular forces and electrostatic repulsion.

In order to improve the sedimentation of such suspended particles (i.e. sludge), their charge must be removed. The following methods can be used in concentrators to accelerate the sedimentation of slime:

(1) Add electrolyte.

(2) Add colloidal surfactant (usually water glass or soda water).

(3) Adjust the liquid-solid ratio in the slurry.

(4) Heat the slurry.

Product Parameter

Model		Concentration tank(m)		Sedimentation area(m²)	Rake part			Motor		Capacity (t/d)
Model	Specification	Inner diameter	Depth	Pool bottom	Mode	Height (m)	Time per revolution(min/r)	Transmission	Lift	Capacity (t/d)
NZS-1	Φ1.8m	1.8	1.8	2.54	Manual English Translation	0.16	2	Y90L-6 1.1KW	----	5.6
NZS-3	Φ3.6m	3.6	1.8	10.2	Manual English Translation	0.35	2.5	Y90L-6 1.1KW	----	22.4
NZS-6	Φ6m	6	3	28.3	Manual English Translation	0.2	3.7	Y90S-4 1.1KW	----	62
NZSF-6	Φ6m	6	3	28.3	Manual English Translation	----	3.7	Y90S-4 1.1KW	----	62
NZ-9	Φ9m	9	3	63.6	Automatic English Translation	0.25	4.34	Y132S-6 3KW	XWD0.8-3 0.8KW	140
NZS-9	Φ9m	9	3	63.6	Manual English Translation	0.25	4.34	Y132S-6 3KW	----	140
NZS-12	Φ12m	12	3.5	113	Manual English Translation	0.25	5.28	JTC752A-44 5.2KW	----	250
NZ-15	Φ15m	15	4.4	176	Automatic English Translation	0.4	10.4	JTC752A-44 5.2KW	Y112M-6 2.2KW	350
NZ-20	Φ20m	20	4.4	314	Automatic English Translation	0.4	10.4	Y100L1-4 5.2KW	Y112M-6 2.2KW	960
NZ-30	Φ30m	30	7.165	707	----	0.61	13.7	Y672A-44 5.2KW	YCJ132-S 1.5KW	----
NZS-45	Φ45m	45	4.633	1590	Manual English Translation	----	20	Y672A-44 5.2KW	YCJ160-S 2.2KW	515
NT-15	Φ15m	15	3.5	177	----	----	8.4	Y132M2-6 5.5KW	----	390
NQ-18	Φ18m	18	3.5	255	----	----	10	Y132M2-6 5.5KW	----	560
NQ-24	Φ24m	24	3.4	452	----	----	12.7	Y160M-6 7.5KW	----	1000
NQ-30	Φ30m	30	3.6	707		----	16	Y160M-6 7.5KW	----	1570
NJ-38	Φ38m	38	4.9	1134	----	----	10-25	JZT252-4 11KW	Y160M-6 7.5KW	1600
NT-45	Φ45m	45	5.05	1590	Automatic English Translation	----	19.3	Y160L-6 11KW	----	2400
NTJ-53	Φ53m	53	5.07	2202	----	----	23.18	Y180L-6 15kw	----	6250
NT-100	Φ100m	100	5.65	7846	----	----	43	Y180L-6 15KW	----	3030
